ANSI SCH80
|
Size |
Do |
d1 |
d2 |
I |
d |
L |
H |
Fig |
|
1/2″ |
30.5 |
21.54 |
21.23 |
24.22 |
16.5 |
75 |
53 |
A |
|
3/4″ |
37.2 |
26.87 |
26.57 |
27.4 |
24 |
85 |
60.5 |
A |
|
1″ |
45.5 |
33.66 |
33.27 |
30.58 |
27.5 |
96 |
72 |
B |
|
1-1/4″ |
54 |
42.42 |
42.04 |
34.75 |
35 |
115.5 |
85 |
A |
|
1-1/2″ |
60 |
48.56 |
48.11 |
37.93 |
41 |
128 |
95 |
B |
|
2″ |
75 |
60.63 |
60.17 |
41.1 |
51.5 |
146 |
111.5 |
B |
|
2-1/2″ |
89 |
73.38 |
72.85 |
47.45 |
65 |
171 |
130 |
A |
|
3″ |
106 |
89.31 |
88.70 |
50.63 |
80 |
197 |
151.5 |
A |
|
4″ |
132 |
114.76 |
114.07 |
60.15 |
100 |
238.5 |
185.5 |
A |
|
5″ |
163.5 |
141.81 |
141.04 |
70 |
136 |
298 |
232 |
B |
|
6″ |
191 |
168.83 |
168 |
79.2 |
150 |
336.5 |
264 |
A |
|
8″ |
246 |
219.84 |
218.69 |
104.6 |
200 |
439.5 |
343 |
A |
|
10″ |
307 |
373.81 |
372.67 |
130 |
265 |
560 |
434 |
B |
|
12″ |
364 |
324.6 |
323.5 |
155 |
315 |
660 |
512 |
B |
|
14″ |
397 |
356.49 |
355.22 |
180 |
346 |
856 |
621 |
A |
GB PN10/DIN PN16
|
Size |
d1 |
d2 |
D |
d |
I |
L |
H |
|
1/2″ |
20.30 |
19.90 |
26.00 |
16.00 |
16.00 |
54.00 |
27.00 |
|
3/4″ |
25.30 |
24.90 |
32.00 |
20.00 |
19.00 |
65.00 |
32.50 |
|
1″ |
32.30 |
31.90 |
41.00 |
27.00 |
22.00 |
80.00 |
40.00 |
|
1-1/4″ |
40.30 |
39.90 |
50.50 |
34.00 |
26.00 |
96.00 |
48.00 |
|
1-1/2″ |
50.30 |
49.90 |
63.20 |
44.00 |
31.00 |
116.00 |
58.00 |
|
2″ |
63.30 |
62.90 |
79.50 |
57.00 |
38.00 |
143.00 |
72.00 |
|
2-1/2″ |
50.30 |
74.90 |
93.00 |
73.50 |
44.00 |
168.00 |
84.00 |
|
3″ |
90.50 |
89.90 |
112.00 |
89.90 |
51.00 |
198.00 |
99.00 |
|
4″ |
110.60 |
109.90 |
133.10 |
109.90 |
61.00 |
238.00 |
119.00 |
|
5″ |
140.85 |
140.05 |
163.00 |
140.00 |
77.00 |
298.00 |
149.00 |
|
6″ |
160.85 |
160.05 |
186.00 |
160.00 |
86.00 |
338.00 |
169.00 |
|
8″ |
226.25 |
225.05 |
261.00 |
225.00 |
119.00 |
469.00 |
234.50 |
|
10″ |
251.45 |
250.05 |
290.00 |
239.00 |
131.00 |
518.00 |
259.00 |
|
12″ |
316.85 |
315.05 |
364.00 |
315.00 |
163.00 |
652.00 |
326.00 |
